UNIT PC EG
UNIT PC EG Premium, Exact and fast EUI and EUP TESTING
Performing complete and accurate test of multi-brand injectors and Pumps
New CAMBOX designed with 5 section original cam;
- VW
- Volvo-Iveco-Scania,
- MB Axor,Atego
- MB Actross,DAF, Mack, Renault
- Cummins
Test plan is divided to 5 groups.
- Bosch PKW (VW group)
- Bosch LKW (MB,DAF,IVECO.SCANIA…)
- Delphi Volvo group (FH 12, 2 pin,4 pin)
- Cummins & CAT & Detroit USA group
- Siemens piezo
**Please check the OPTIONAL tab below to see additional auxiliary tools for other models.
Fill the Form, Get a Price List!
UNIT PC EG - Diesel Unit Injector Test Machine
UNIT PC EG has reduced setup and test times as well as user friendly operation menu.
Controls all types and makes of unit injectors & pumps.
Actuator valve measurement via BIP sensor and delay time measurements with follow oscillascope.
Easy and oil free change of cam with sliding plate.
Perfect angle reseting for each cam shafts.
Dynamic electronic mass measurement.
You can check the unit injectors such as Cummins, Caterpillar, Detroit, and and injection system HPI (optional)
It contains test plans of injector and pump types of many brands in the market.
Software updates and test plans can be loaded with remote desktop free of charge.
10 pieces adaptors is given free by the bench
| Supply voltage | AC 380 (3P+N+GND) |
| Motor Power | 15 Hp |
| Low Pressure | 1 – 8 bar |
| RPM | 0-2000 rpm adjustable |
| Inj Weight Sensor Range | 0.1 – 500 cc /min |
| Back Flow Sensor Range | 1-300 L/h |
| Dimensions (L x H x W) | 180x165x87 cm |
| Weight | 660 Kg |
| Oil Tank Capacity/Type | 20 lt (ISO 4113) |
| Power Output (duration) | 8 Kw |
| Code | Description | Pieces |
| CAMBOX 132 (5 CAM) | 1 pcs | |
| 3.02.15.048 | Cam shaft pusher 1st cam | 1 pcs |
| 3.02.15.050 | Cam shaft pusher 2nd cam | 1 pcs |
| 3.02.15.051 | Cam shaft pusher 3th cam | 1 pcs |
| 3.02.15.052 | Cam shaft pusher 4th cam | 1 pcs |
| 3.02.15.053 | Cam shaft pusher 5th cam | 1 pcs |
| 1.02.02.033 | Bosch PDE 1 Type Inj. Test Adaptor | 1 pcs |
| 1.02.02.031 | Siemens&Bosch VW PDE2 Type Inj. Test Adaptor | 1 pcs |
| 1.02.02.018 | Delphi EUI E1/E3 Inj. Test Adaptor | 1 pcs |
| 1.02.02.029 | Bosch EUI Scania Type Inj Test Adaptor | 1 pcs |
| 1.02.02.017 | Bosch EUI Iveco 8-10 Type Inj Test Adaptor | 1 pcs |
| 1.02.02.018 | Bosch EUP Actross Type Pump Test Adaptor | 1 pcs |
| 1.02.02.019 | Bosch EUP Axor/Atego Type Pump Test Adaptor | 1 pcs |
| 1.02.02.025 | Cummins Celectt EUI Type Inj Test Adaptor | 1 pcs |
| 1.02.02.026 | Bosch/Delphi EUP Daf Pump Test Adaptor | 1 pcs |
| 1.02.02.017 | Bosch/DelphiEUI Iveco/Volvo Type Inj Test Adaptor | 1 pcs |
| 1.01.11.020 | Selenoid Inj&pump Main Test Cable | 1 pcs |
| 1.01.11.021 | Piezo Inj Main Test Cable | 1pcs |
| 1.01.11.009 | Delphi 2 Pin Inj Test Cable | 1 pcs |
| 1.01.11.010 | Delphi 4 Pin Inj Test Cable | 1 pcs |
| 1.01.11.022 | Bosch EUI PKW Inj. Test Cable | 1 pcs |
| 1.01.11.023 | Bosch EUP LKW pump test cable | 1 pcs |
| 1.01.11.004 | LKW Type Inj. Cable | 1 pcs |
| 1.01.11.009 | Universal Inj Test Cable | 1 pcs |
| Inj – Pump Connection Screw Set (12 pcs) | 1 set | |
| Injector and Pump Spacer Set (6 pcs) | 1 set | |
| 4.02.05.026 | Test Injector for LKW Pumps | 1 pcs |
| 4.02.13.027 | Pipe 6×2 mm 600 mm 14X14 | 1 pcs |
| 4.02.16.089 | Inlet and Outlet hoses | 1 Set |
| 3.02.15.054 | Dummy Fixture for calibration | 1 pcs |
| 4.02.12.148 | Installation USB Flash disk | 1 pcs |
SOME INJECTORS AND PUMPS REQUIRED EXTRA EQUIPMENTS AND ACCESSORIES. PLEASE CONTACT US ABOUT YOUR TYPES
